Car toggle switch 20A, SPST red LED-illuminated toggle switch for 12 V DC systems, on-off, 2 positions, with LED, for cars trucks boatsASW-15D

Product Description:

This is a unique SPST ON / OFF LED illuminated (red) toggle switch.

Press the handle to select different functions depending on the position. Rated voltage 12V DC, rated current: 20A DC.

Rating 20A 12V DC, 3 terminal pins, Perfect for customized wiring or switch replacement, Blade terminals facilitate wiring and installation

Sturdy construction, plastic and metal, exquisite appearance, anti-rust, corrosion resistance, safety and durability, easy to install. Positive with plus, minus with minus, whether to connect the LED light to your needs, you decide.

Wide compatibility, control the on and off of the AC and DC power supply circuit can be independent or interlocked with other switches.

Visual feedback, Lighted toggle switches operate on 12 volts DC and light up to provide visual feedback on the operation of your circuit.

Wide Application, Suitable for almost all motorized vehicles such as cars, boats, ATVs, UTVs, airplanes, RVs, race cars, golf carts, any off-road vehicle, truck and industrial applications.

Overall size (approximate): 26 x 12 x 61 mm

Technical Description:

DC 12V/20A, 3 connection pins

Dimensions of the mounting hole: Ø 12mm

With fixing nut.

Installation depth 25 mm
